SGW-10A Fully Automatic Four Ball Friction and Wear Testing Machine

    SGW-10 computer control automatic four-ball friction testing machine, in the form of slide friction, is used for the loading capacity evaluation of lubricants in the high pressure point contact condition. It can test the maximum nonseizure load PB, sintered load PD and composite wear value ZMZ of lubricants.The four-ball friction test machine can also be used as lubricant for long time wear resistance test, determination of friction coefficient, recording friction and temperature curve. It also can measure the dimension of the wear scar and display,measurement and recording the wear scar on the PC screen.The wear resistance of metallic materials or non-metallic materials can also be studied with special attachments.

Patent NO：ZL201820682290.6,ZL201830226679.5,ZL20180682131.6

With many patents, our company has advanced R & D technology and keen innovation ability. The product has high precision, easy operation, easy maintenance and no oil source pollution.

Two.Technical parameters

1 Test force

1.1 Axial test force range   40~10000N

1.2 Relative accuracy of test force display ±1%（0.5）

1.3 Accuracy of testing force display for a long time ±1%F.S（0.5）

1.4 Loading way Full automatic loading (non-hydraulic, state related patent)

2 Friction torque

2.1 Measuring range of friction torque 0~13500N.mm

2.2 Relative Accuracy of the friction torque display ±2%

3 Spindle speed

3.1 Spindle frequency conversion speed range 10~2000rpmin

3.2 Accuracy of Spindle speed ±5rpmin

4 The oil box stroke >45mm

5 Spindle bore taper 1：7

6 The heating system

6.1 Heater working temperature range Room temperature～250℃

6.2 Accuracy of temperature ≤2℃

7 Testing machine control

7.1 The control mode Whole process touch screen control (dual function)

7.2 Test time display and control range 1~99999s or 1~99999min

7.3 Test machine revolution display and control range 999999999

7.4 Test machine main motor Taiwan TECO servo motor

8 A test oil quantity About 10ml

9 Diameter of  special standard steel ball for test 12.7

10 Test machine size（L×W×Hmm） About 1160×750×1640

11 Weight About 400kg

12 Rated power of testing machine 5.5KW

Three.Standards

ASTM D 4172 Standard Test Method for Wear Resistance of Lubricating Fluid (Four-Ball Method)

ASTM D2266-01 Standard Test Method for Friction and Wear of Lubricating Oil (Four-Ball Method)

ASTM D2783-2003 (2009) Standard Test Method for Measurement of Extreme-Pressure Properties of Lubricating Fluid (Four-Ball Method)

ASTM D2596-2010 Standard Test Method for Measurement of Extreme-Pressure Properties of Lubricating Grease (Four-Ball Method)

GB/T12583-98 Determination of Extreme Pressure Properties of Lubricants (Four-Ball Method)

GB3142-82 Determination of the Bearing Capacity of Lubricants (Four-Ball Method)

SH/T0189-92 Determination of Oil Wear Resistance (Four-Ball Method)

SH/T0202-92 Determination of Extreme Pressure Properties of Grease (Four-Ball Method)

Four.Functional Characteristics

&.Basic Functional Characteristics

Test the maximum non stick load Pb, sintering load Pd, comprehensive wear value ZMZ, D value and other indicators of the lubricant

Long term wear resistance test of lubricants, determination of friction coefficient

Special test for lubricating oil: friction coefficient step test (SH0762/ASTM5183)

Rapid expansion of KRL lubricant shear test (SH0845)

Improve lubricating oil process and control the optimal economic ratio of formula

&.Standard Features

Load: direct real-time measurement of contact load without conversion, benchmarking against specific requirements of ISO/ASTM/GB/SH and other standards

Operation: parameter setting, level selection, minimalist operation, improve work efficiency, and reduce operational errors

&.High-End Upgradable Functions

Fully automatic: with a high degree of automation, after installing the sample, you can enter the fully automatic test (only 2 keys are needed)

Accuracy: load and friction force can be self calibrated during startup, and friction force can also be equipped with dual sensors to improve absolute accuracy

Grinding spot: the grinding spot diameter directly displays the reference value and quickly locks the level (without the need for a microscope)

Judgment: PB and PD multi-directional online judgment to improve accuracy and equipment service life (ms level protection)

Extension function: it can quickly carry out step tests for friction coefficient (SH0762/ASTM5183) and convert KRL lubricating oil shear tests (SH0845)

Quick comparison: develop new oil products without the need for a microscope, quickly calculate the comprehensive wear performance ZMZ index
